Portable Breast Disease Treatment Instrument EK-8000BQ

Product Detail

Product Overview

The breast disease treatment device integrates three mechanisms of action—microcomputer simulation control, infrared photothermal radiation, electrical pulse stimulation, and drug iontophoresis—based on traditional Chinese medicine meridian therapy and other traditional and modern treatment methods, allowing them to interact and treat simultaneously.

Technical Principles

1. Electrical pulse stimulation: Simulates acupuncture effects through intelligent bio-waves of different frequencies, regulating neuromuscular excitability to achieve analgesia and endocrine regulation.

2. Infrared light irradiation: Utilizes near-infrared light with wavelengths of 0.8-3μm to penetrate 4cm of tissue, promoting local microcirculation and cell metabolism, effectively eliminating breast tissue congestion.

3. Magnetic therapy: Adjusts cell polarity through magnetic induction intensity, reducing the concentration of inflammatory factors to achieve anti-swelling and analgesic effects.

4. Drug delivery: Employs ion current-driven targeted drug penetration, increasing drug concentration in the lesion area by 5-8 times.

Applicable diseases

Suitable for the comprehensive treatment of mastitis and breast hyperplasia using electrical stimulation massage, infrared heat radiation, and drug iontophoresis.

Main parameters

1. The therapeutic device offers 7 selectable treatment modes; the electrical pulse intensity is adjustable from 0 to 99 levels.

2. The infrared radiation intensity level is adjustable from 1 to 18, with increasing intensity levels. When the infrared radiation intensity is set to the strongest level 18, the probe surface temperature should be ≤60℃ within 30 minutes. Near-infrared light wavelength: 0.8μm～3μm.

3. It features voice function and treatment time reminder.

4. The therapeutic device's working time is continuously adjustable within the range of 0 to 99 minutes.

5. It comes standard with 2 probes. Probe 1 uses conductive rubber that directly contacts the human body and is made of green materials under SGS standards. During treatment, the patient can place the probe directly inside their bra, eliminating the need to hold it, making the treatment more comfortable.

6. It has 2 independent output channels.

7. The integrated streamlined design is compact, with a simple and stylish appearance, making it easy to move.
